GATOR NITRO-X FINE JOINT SAND is the ideal air cure, low permeability jointing material. It is a ready-to-use mixture of calibrated fine sand and new proprietary resin formula which cures when exposed to air, hardening from top to bottom of the joint. The product can be installed in wet or dry weather. The Rapid Flow Technology makes it fast and simple to Install.

Ideal For:

Concrete pavers, concrete slabs, natural stones or wet cast stones
Outdoor porcelain tiles, porcelain pavers or porcelain slabs
Residential driveways with light vehicular use
Patios, pool areas and walkways

Features:

Traditional drainage base
Permeable base
Hybrid base
Gator Base (for pedestrian use only)
Joint width of 1/8” (3 mm) to 1/4” (6 mm) for outdoor porcelain tiles, porcelain pavers or porcelain slabs
Joint width of 1/8” (3 mm) to 2” (50 mm) for concrete pavers, concrete slabs, natural stones or wet cast stones
Joint depth min 3/4” (20 mm) to a max 2-3/8” (60 mm)
RAPID FLOW TECHNOLOGY
Fast and simple installation
Xtra fine gradation jointing sand
Xtra low permeability
Apply rain or shine
Xtra strength from top to bottom
Works above 37°F (3°C)
The concrete pavers, concrete slabs, natural stones or wet cast stones and the outdoor porcelain tiles, porcelain pavers or porcelain slabs must have no movement prior to, or after the installation of GATOR NITRO-X into the joints. If the concrete pavers, concrete slabs, natural stones or wet cast stones and the outdoor porcelain tiles, porcelain pavers or porcelain slabs move or rotate, this is due to improper sub-base preparation. For clarity, GATOR NITRO-X, will not prevent lateral or rotational forces that are generated to the concrete pavers, concrete slabs, natural stones or wet cast stones and the outdoor porcelain tiles, porcelain pavers or porcelain slabs installations. Any movement on any paving material will void the warranty.

Maintenance:

MAINTENANCE OF PAVED SURFACE When maintaining the paved surface, apply Gator Shampoo to clean the entire surface including the stone joints. Wash, rinse and remove any residue by using a hose and a watering gun set to shower with the normal maximum water pressure from any residential or commercial building (typically 80 psi/550 kPa). GATOR NITRO-X has a low permeability when installed. However, If not maintained properly, permeability will be obstructed over time. To avoid obstruction in the joints, periodically use a pressure washer to remove all dirt and debris. Wait 28 days after the initial application of GATOR NITRO-X before using a pressure washer MOSS GATOR NITRO-X will not cause nor prevent moss, mold or mildew. Moss, mold and mildew are caused by certain on-site conditions including excess moisture, shade, absence of ventilation, inadequate cleaning or maintenance, presence of soil or other organic debris left on the product.

Coverage:

The quantity required depends on the size of the joints. One pail of 27.5 lb (12.5 kg). Paver Or Stone 12″ x 12″ x 2-3/8″ (30 cm x 30 cm x 6 cm). Porcelain tile 24″ x 24″ x 3/4″ (60 cm x 60 cm x 2 cm).

Porcelain tile 24″ x 24″ x 3/4″ with 1/8″ joint width (60 cm x 60 cm x 20 mm with 3 mm joint width) • Paver or stone 12″ x 12″ x 2-3/8″ with joints 3/16″ to 1″ (30 cm x 30 cm x 60 mm with joints 5 mm to 25 mm)	Taupe	Platinum	Gunmetal	Black	Vanilla
1/8″ joint (Porcelain tile)	374 sq. ft.	348 sq. ft.	348 sq. ft.	323 sq. ft.	374 sq. ft.
3 mm joint (Porcelain tile)	35 sq. m.	33 sq. m.	33 sq. m.	31 sq. m.	35 sq. m.
1/8″ joint (Concrete paver)	64 sq. ft.	59 sq. ft.	59 sq. ft.	54 sq. ft.	64 sq. ft.
3 mm joint (Concrete paver)	6 sq. m.	5.5 sq. m.	5.5 sq. m.	5.1 sq. m.	6 sq. m.
3/16” joint (Concrete paver)	38 sq. ft.	35 sq. ft.	35 sq. ft.	33 sq. ft.	38 sq. ft.
5 mm joint (Concrete paver)	3.6 sq. m.	3.3 sq. m.	3.3 sq. m.	3.1 sq. m.	3.6 sq. m.
3/4” joint (Concrete paver)	10.4 sq. ft.	9.6 sq. ft.	9.6 sq. ft.	9 sq. ft.	10.4 sq. ft.
20 mm joint (Concrete paver)	0.97 sq. m.	0.9 sq. m.	0.9 sq. m.	0.84 sq. m.	0.97 sq. m.
1″ joint (Concrete paver)	8 sq. ft.	7 sq. ft.	7 sq. ft.	6.8 sq. ft.	8 sq. ft.
25 mm joint (Concrete paver)	0.75 sq. m.	0.69 sq. m.	0.69 sq. m.	0.65 sq. m.	0.75 sq. m.

Sand Calculator

Storage Time:

24 months in a cool area. Excess material can be stored directly in the pail with 2″ of water covering the GATOR NITRO-X FINE JOINT SAND and closing the pail tightly, It may last up to 4 weeks longer. Always store the product indoors.

Packaging:

Product	Size	Units per Pallet
GATOR NITRO-X FINE JOINT SAND – Black	27.5 lb (12.5 kg)	48
GATOR NITRO-X FINE JOINT SAND – Gunmetal	27.5 lb (12.5 kg)	48
GATOR NITRO-X FINE JOINT SAND – Taupe	27.5 lb (12.5 kg)	48
GATOR NITRO-X FINE JOINT SAND – Platinum	27.5 lb (12.5 kg)	48
GATOR NITRO-X FINE JOINT SAND – Vanilla	27.5 lb (12.5 kg)	48
